Auto loader
Automatic Mold Temperature Control
La température instable dans le processus de moulage a toujours tendance à produire des produits non qualifiés, selon le principe de l'échange de chaleur. Le contrôle de la température des moules TH-M utilise l’eau et une huile de transfert de chaleur à propriétés élevées en tant que moyen permettant de maintenir une température raisonnable dans le processus de moulage, afin de garantir une haute qualité des produits et d’accroître le rendement.
Chiller
| Technical parameter list of water-cooled Chiller. | |||||||||||||
| Model NO. | TH-05WCI | TH-08WCI | TH-10WCI | TH-12WCI | TH-15WCI | TH20WCI | TH-25WCI | TH-30WCI | TH-40WCI | TH-50WCI | TH-60WCI | ||
| Rated Cooling capacity | kw | 16.3 | 26.2 | 34.4 | 39.4 | 52.4 | 68.8 | 78.8 | 103.2 | 140 | 160 | 208.0 | |
| Kcal/h | 14018 | 22532 | 29584 | 33884 | 45064 | 59168 | 67768 | 88752 | 120400 | 137600 | 178880 | ||
| USRT | 4.63 | 7.45 | 9.78 | 11.20 | 14.90 | 19.56 | 22.41 | 29.34 | 39.81 | 45.49 | 59.14 | ||
| COP | 4.9 | 5.2 | 5.2 | 5.3 | 5.2 | 5.2 | 5.3 | 5.2 | 5.3 | 5.3 | 5.1 | ||
| Frozen Medium | Neutral water | ||||||||||||
| Input Power | 380V ,3 Ph , 50HZ | ||||||||||||
| Compressor | Mode | High efficient full -hermetic scroll type compressor | |||||||||||
| Quantity | 1 | 1 | 2 | 1 | 2 | 2 | 2 | 3 | 4 | 4 | 4 | ||
| Input Power | 3.3 | 5 | 6.6 | 7.5 | 10 | 13.2 | 15 | 19.8 | 26.4 | 30 | 40.8 | ||
| Rated load current ( A ) | 7 | 9.9 | 12.7 | 13.8 | 19.8 | 25.4 | 27.6 | 38.1 | 50.8 | 55.6 | 84 | ||
| Matching wire mm2 | 1.5 | 2.5 | 4 | 4 | 6 | 10 | 16 | 16 | 16 | 25 | 25 | ||
| Refrigerant | R22 / R407C / R502 | ||||||||||||
| Water Cooled Condenser | Mode | High efficient outside screwed shell and tube | |||||||||||
| Cooling water Flow m3/h | 3.4 | 5.4 | 7.1 | 8.1 | 10.7 | 14.1 | 16.1 | 24.3 | 28.6 | 32.7 | 42.8 | ||
| Cooling water Temperature ℃ | Inlet 30 ℃ / Outlet 35 ℃ | ||||||||||||
| Pump | Power (kw) | 0.37 | 0.75 | 0.75 | 0.75 | 1.5 | 1.5 | 2.2 | 2.2 | 3 | 3 | 4 | |
| Flow (L/min) | 1.2 | 1.2 | 1.2 | 1.2 | 6.0 | 6.0 | 6.0 | 6.0 | 30.0 | 30.0 | 50.0 | ||
| Max.Pump head （m ) | 17.7 | 28.2 | 28.2 | 28.2 | 23.2 | 23.2 | 28.2 | 28.2 | 19.0 | 19.0 | 18.0 | ||
| Evaporator | Mode | High efficient intside screwed shell and tube / water tank Immersion ( up 10HP ) | |||||||||||
| Ice water flow m3/h | 2.8 | 4.5 | 5.9 | 6.8 | 9.0 | 11.8 | 13.6 | 17.8 | 24.1 | 27.5 | 35.8 | ||
| Ice water inlet & outlet Temperature ℃ | Inlet 20 ℃/ Outlet 15 ℃ | ||||||||||||
| Throttle Methods | External balance expansion valve | ||||||||||||
| Safety Protection | 1.Water Pump interlock protection / 2. leakage protection / 3.overload protection / 4. overpressure and anti-phase protection / 5. refrigerant abnormality protection / 6. compressor over temperature protection / 7. and lack of water protection / |
||||||||||||
| Piping Connetion | Cooling water in&outlet diameter | Ø 32 | Ø 50 | Ø 50 | Ø 50 | Ø 63 | Ø 63 | Ø 63 | Ø 63 | Ø 76 | Ø 76 | Ø 89 | |
| Ice water in&outlet diameter | Ø 32 | Ø 50 | Ø 50 | Ø 50 | Ø 63 | Ø 63 | Ø 63 | Ø 63 | Ø 76 | Ø 76 | Ø 89 | ||
| Weight kg | 130 | 200 | 230 | 260 | 300 | 400 | 500 | 630 | 950 | 1260 | 1600 | ||
| Size L.W.H mm | 1200 x 750 x 1100 | 1200 x 750 x 1100 | 1350 x 750 x 1150 | 1350 x 750 x 1150 | 1750 x 800 x 1300 | 1750 x 800 x 1300 | 2000 x 950 x 1300 | 2000 x 950 x 1300 | 2300 x 1000 x 1450 | 2600 x 1000 x 1600 | 2900 x 1200 x 1800 | ||
| Remark: 1. Working conditions : Chilled water Temperature 20 ℃ \ 15 ℃ . 2.The Product dimensions are based on the actual product, and the technical parameters have been changed due to product improvement,Without notice. |
|||||||||||||
| Technical parameter List of Air-cooled Chiller | ||||||||||||||
| Model NO. | TH-03ACI | TH-05ACI | TH-08ACI | TH-10ACI | TH-12ACI | TH-15ACI | TH20ACI | TH-25ACI | TH-30ACI | TH-40ACI | TH-50ACI | TH-60ACI | ||
| Rated Cooling capacity | kw | 9 | 15 | 23.6 | 31.2 | 35.5 | 47.2 | 62.4 | 71 | 92.0 | 128.0 | 144.0 | 184.0 | |
| Kcal/h | 7740 | 12900 | 20296 | 26832 | 30530 | 40592 | 53664 | 61060 | 79120 | 110080 | 123840 | 158240 | ||
| USRT | 2.6 | 4.3 | 6.7 | 8.9 | 10.1 | 13.4 | 17.7 | 20.2 | 26.2 | 36.4 | 40.9 | 52.3 | ||
| COP | 3.8 | 3.8 | 3.9 | 3.9 | 3.9 | 3.9 | 3.9 | 3.9 | 3.7 | 4.0 | 3.9 | 3.7 | ||
| Frozen Medium | Neutral water | |||||||||||||
| Input Power | 380V ,3 Ph , 50HZ | |||||||||||||
| Compressor | Mode | High efficient full -hermetic scroll type compressor | ||||||||||||
| Quantity | 1 | 1 | 1 | 2 | 1 | 2 | 2 | 2 | 3 | 4 | 4 | 4 | ||
| Input Power （KW） | 2.4 | 4 | 6.1 | 8.1 | 9.2 | 12.2 | 16.2 | 18.4 | 24.8 | 32.4 | 36.8 | 49.6 | ||
| Rated load current ( A ) | 4.4 | 7.8 | 11.6 | 14.6 | 16.2 | 23.2 | 29.2 | 32.4 | 47.8 | 58.4 | 64.8 | 95.6 | ||
| Matching wire mm2 | 1.5 | 1.5 | 2.5 | 4 | 4 | 6 | 10 | 16 | 16 | 16 | 25 | 25 | ||
| Refrigerant | R22 / R407C / R502 | |||||||||||||
| Air Cooled Condenser | Mode | High efficient intside screw tube shinizu fin style | ||||||||||||
| Heat exchange Area / m2 | 30 | 50 | 80 | 100 | 120 | 160 | 200 | 250 | 300 | 400 | 500 | 600 | ||
| Cooling Method / Cooling Fan Power: W | 180 | 250 | 500 | 900 | 900 | 1200 | 1200 | 1800 | 1800 | 3400 | 4800 | 5100 | ||
| Pump | Power (kw) | 0.37 | 0.37 | 0.75 | 0.75 | 0.75 | 1.5 | 1.5 | 2.2 | 2.2 | 3 | 3 | 3 | |
| Flow (m3/h) | 1.2 | 1.2 | 1.2 | 1.2 | 1.2 | 6.0 | 6.0 | 6.0 | 6.0 | 30.0 | 30.0 | 50.0 | ||
| Max.Pump head （m ) | 17.7 | 17.7 | 28.2 | 28.2 | 28.2 | 23.2 | 23.2 | 28.2 | 28.2 | 19.0 | 19.0 | 13.0 | ||
| Evaporator | Mode | Coil form | High efficient inside screwed shell and tube / water tank immersion ( up to 10HP) | |||||||||||
| Ice water flow m3/h | 1.5 | 2.6 | 4.1 | 5.4 | 6.1 | 8.1 | 10.7 | 12.2 | 15.8 | 22.0 | 24.8 | 31.6 | ||
| Ice water inlet & outlet Temperature ℃ | Inlet 20 ℃/ Outlet 15℃ | |||||||||||||
| Throttle Methods | External balance expansion valve | |||||||||||||
| Safety Protection | 1.Water Pump interlock protection / 2. leakage protection / 3.overload protection / 4. overpressure and anti-phase protection / 5. refrigerant abnormality protection / 6. compressor over temperature protection / 7. lack of water protection / |
|||||||||||||
| Piping Connetion | Ice water in&outlet diameter | Ø 32 | Ø 32 | Ø 50 | Ø 50 | Ø 50 | Ø 63 | Ø 63 | Ø 63 | Ø 63 | Ø 76 | Ø 76 | Ø 89 | |
| Weight kg | 220 | 240 | 335 | 430 | 550 | 630 | 790 | 880 | 1260 | 1680 | 2110 | 2520 | ||
| Size L.W.H mm | 950 x 700 x 1200 | 1100 x 750 x 1300 | 1500 x 750 x 1350 | 1550 x 820 x 1300 | 1750 x 820 x 1300 | 1900 x 950 x 1400 | 1950 x 1050 x 1540 | 2500 x 1000 x 1500 | 2650 x 1050 x 1540 | 2810 x 1200 x 1650 | 2950 x 1250 x 1720 | 3100 x 1400 x 1850 | ||
| Remark: 1. Working conditions : Chilled water Temperature 20 ℃ \ 15 ℃ . 2.The Product dimensions are based on the actual product, and the technical parameters have been changed due to product improvement,Without notice. |
||||||||||||||
Crusher
"The knife tool is refined with imported special tool-steel. the clearance between knife tools are adjustable . when it becomes blunt by using , it can be dismounted repeatedlly . it is Durable ."
1.Use high-intensity steel screws to fasten the knife leaf and knife seat , having strong bearing capacity .
2. All walls of crushing chamber are treated by sound-proof, so having extra-low noise
3. A disconnect-type designed , the bunker, main body, Sieve can be dismounted for cleaning easily, heavey bearing with dust protection device .
4. The Motor has over-loading protection with power source interlock protection device . Double- safely protection for operatiorand motor .
5. Step-type motion knife design with strong breaking capacity.
6. Equipped vibration feet on TH-F500, Reduce noise of vibration .
Hopper Dryer
Mixer
